BLUSTREAM Multi-Format Presentation Switch

The WMF72 is an advanced 4K multi-format presentation switch featuring wired HDMI and USB-C, AirPlay, Miracast® and Chromecast® inputs to dual HDMI outputs.The WMF72 provides enhanced features including dual HDMI output for mirrored or managed source control with multiview presentation, video scaling and web-GUI for control and configuration, localised 2.4/5G WiFi hotspot, and dual LAN connection. The WMF72 also features OSD control, USB camera and MIC over WiFi, USB touch-back to connected host device, whiteboard and screen overlay annotation, manual or automated source selection, and control via front panel, RS-232 and TCP/IP.The WMF72 is also compatible with Blustream WMF-USBC-D and WMF-HDMI-D plug & play wireless dongles, providing an ideal BYOD solution for your boardroom, classroom or huddle-space application.Key Features:4K multi-format multi-view presentation switchFeatures HDMI, USB-C, AirPlay, Miracast®, Chromecast® and Blustream wireless dongle support which can be switched to dual HDMI outputsDual HDMI output supports mirror or desktop extension for managed soure control within advanced video conferencing set-upsMultiview presentation with up to 5 concurrent video signals and configurable screen layoutIn-built video scaler with output timing up to 4K 60Hz 4:4:4USB-C connection for BYOM, with DP, USB, 1Gbps network and up to 65W power chargingHDMI & USB Type B connection for BYOM, with USB and 1Gbps network via USB Type B connectionLocalised 2.4G/5G WiFi hotspot to host AirPlay, Miracast® and Chromecast® local point-to-point mode (up to 1080p 30Hz)Dual LAN connection for integration to existing network infrastructuresSupports USB camera and MIC over WiFi up (1080p 30Hz)Supports USB touch-back feature via WMF-USBC-D and WMF-HDMI-D dongles and Miracast®**Audio breakout to balanced / unbalanced analogue L/R audioWeb interface module for control and configuration of switchOSD control with preview functionWhiteboard and screen overlay annotation featureControl via front panel, RS-232 and TCP/IP with manual or auto source selection**Miracast touch-back compatibility subject to Windows features**Specifications:Video input: 1 x HDMI Type A, female, 1 x USB Type C, femaleVideo Output Connectors: 2 x HDMI Type A, 19-pin, femaleAudio Output Connectors: 5-Pin Phoenix connector (2ch balanced/un-balanced analogue audio)RS-232 serial port: 1 x 3-Pin Phoenix connectorTCP/IP Control: 2 x RJ45, female (1000Mbps x2)USB Connectors: 3 x USB3.0 Type A female, 1 x USB3.0 Type B femaleUSB Touchback Connectors: 2 x USB2.0 Type A femaleUSB Pairing Connectors: 1 x USB2.0 Type A female, 1 x USB-C2.0 Type C WiFi - 3 x SMA, female connector, MIMO antennas (2.4G & 5G, WiFi IEEE 802.11 b/g/n/ac up to 1200Mbps)WiFi Encryption - AES WPA PSK, WPA2 PSKCasing Dimensions (W x H x D): 220mm x 27mm x 161mm (excluding antennas)Shipping Weight: 2kgOperating Temperature: 0°C to 45°C (32°F to +113°F)Storage Temperature : -20°C to 70°C (-4°F to +158°F)Power Supply: 24V/5A DC
