WHYTE Series 5 2 Way Splitter 5dB Loss

Whyte Series 5 Taps & Splitters are a range of 5 wire passive devices that distribute SAT and Terrestrial Signals. The range includes 1 way, 2 way and 3 way Taps with either a 10dB or 20dB tap off and a 2 way Splitter. For ease of installation, each Tap comes complete with a set of high quality colour coded 600mm F-type leads which enables the Multiswitches to be positioned either side of the Tap and to be orientated vertically or horizontally depending on available space.Main Features:Inbuilt LTE filterLED power indicatorColour coded inputs and outputsTap outputs on top of unit for easy accessWhyte Taps, Splitters and Multiswitches can be used to configure Integrated Reception Systems (IRS) to suit your applicationSpecifications:Frequency:SAT: 950-2150MHzTERR: 87-790MHzInputs (F-Type Connector):4 SAT + 1 TERROutputs (F-Type Connector):3× 4 SAT3× 1 TERRDC Input (Injection of DC applied to):SAT Trunks HL + HHDC Pass Trunk To Tap:SAT: AllTERR: NoSplitter Loss:SAT: 4dB±1dBTERR: 4dB±1dBFixed Slope Tap (SAT):4dBIsolation:>30dBMax Current Pass (Trunk/Split):2APower Indication:LEDDimensions (mm):156 x 136 x 43Weight:376g
